| Ø Tubi DE - Ø Pipe DE | BOX | CODE | A | B | L | Kg |
|---|---|---|---|---|---|---|
| 110 | 1 | 5T310011006110 | 1'' | 189 | 115 | 3,5 |
| 110 | 1 | 5T310011007110 | 1''1/4 | 189 | 115 | 3,5 |
| 110 | 1 | 5T310011008110 | 1''1/2 | 186 | 115 | 3,5 |
| 110 | 1 | 5T310011010110 | 2'' | 189 | 115 | 3,5 |
| 125 | 1 | 5T310012506125 | 1'' | 204 | 115 | 3,8 |
| 125 | 1 | 5T310012507125 | 1''1/4 | 204 | 115 | 3,8 |
| 125 | 1 | 5T310012508125 | 1''1/2 | 204 | 115 | 3,8 |
| 125 | 1 | 5T310012510125 | 2'' | 204 | 115 | 3,8 |
| 140 | 1 | 5T310014006140 | 1'' | 219 | 140 | 4,7 |
| 140 | 1 | 5T310014007140 | 1''1/4 | 219 | 140 | 4,7 |
| 140 | 1 | 5T310014008140 | 1''1/2 | 219 | 140 | 4,7 |
| 140 | 1 | 5T310014010140 | 2'' | 219 | 140 | 4,7 |
| 160 | 1 | 5T310016006160 | 1'' | 239 | 140 | 5,2 |
| 160 | 1 | 5T310016007160 | 1''1/4 | 239 | 140 | 5,2 |
| 160 | 1 | 5T310016008160 | 1''1/2 | 239 | 140 | 5,2 |
| 160 | 1 | 5T310016010160 | 2'' | 239 | 140 | 5,2 |
| 180 | 1 | 5T310018006180 | 1'' | 259 | 180 | 7,7 |
| 180 | 1 | 5T310018010180 | 2'' | 259 | 180 | 7,7 |
| 200 | 1 | 5T310020006200 | 1'' | 279 | 180 | 8,00 |
| 200 | 1 | 5T310020007200 | 1''1/4 | 279 | 180 | 8,00 |
| 200 | 1 | 5T310020008200 | 1''1/2 | 279 | 180 | 8,00 |
| 200 | 1 | 5T310020010200 | 2'' | 279 | 180 | 8,00 |
| 225 | 1 | 5T310022507225 | 2'' | 304 | 180 | 9,00 |
| 250 | 1 | 5T310025007250 | 1''1/4 | 329 | 180 | 9,8 |
| 250 | 1 | 5T310025010250 | 2'' | 329 | 180 | 9,8 |
| 280 | 1 | 5T310028010280 | 2'' | 359 | 180 | 10,6 |
| 315 | 1 | 5T310031510315 | 2'' | 394 | 180 | 13,00 |
| 50 | 1 | 5T3100500550 | 3/4'' | 114 | 90 | 1,4 |
| 50 | 1 | 5T3100500650 | 1'' | 114 | 90 | 1,4 |
| 50 | 1 | 5T3100500750 | 1''1/4 | 114 | 90 | 1,4 |
| 63 | 1 | 5T3100630663 | 1'' | 129 | 90 | 1,7 |
| 63 | 1 | 5T3100630763 | 1''1/4 | 129 | 90 | 1,7 |
| 63 | 1 | 5T3100630863 | 1''1/2 | 129 | 90 | 1,7 |
| 63 | 1 | 5T3100631063 | 2'' | 129 | 90 | 1,7 |
| 75 | 1 | 5T3100750675 | 1'' | 141 | 115 | 2,3 |
| 75 | 1 | 5T3100750775 | 1''1/4 | 141 | 115 | 2,3 |
| 75 | 1 | 5T3100750875 | 1''1/2 | 141 | 115 | 2,3 |
| 75 | 1 | 5T3100751075 | 2'' | 141 | 115 | 2,3 |
| 90 | 1 | 5T3100900690 | 1'' | 161 | 115 | 2,8 |
| 90 | 1 | 5T3100900790 | 1''1/4 | 161 | 115 | 2,8 |
| 90 | 1 | 5T3100900890 | 1''1/2 | 161 | 115 | 2,8 |
| 90 | 1 | 5T3100901090 | 2'' | 161 | 115 | 2,8 |
