| 1 |
BODY |
BRASS CW617N UNI EN 12165 |
1 |
| 2 |
STEM |
BRASS CW614N UNI EN 12164 |
1 |
| 3 |
REGULATING RING |
BRASS CW614N UNI EN 12164 |
1 |
| 4 |
SPRING |
STEEL C85 CL C UNI 10083 |
1 |
| 5 |
MALE UNION TALE |
BRASS CW617N UNI EN 12165 |
1 |
| 6 |
SHUTTER SEAL |
NBR |
1 |
| 7 |
CAP |
PA6.6 |
1 |
| 8 |
WHEEL HANDLE |
ABS |
1 |
| 9 |
SUPPORT |
PSU |
1 |
| 10 |
CAP FOR PRESSURE GAUGE |
POM |
1 |
| 11 |
O-RING |
NBR |
1 |
| 12 |
O-RING |
NBR |
1 |
| 13 |
O-RING |
NBR |
1 |
| 14 |
O-RING |
NBR |
1 |
| 15 |
O-RING |
NBR |
1 |
| 16 |
O-RING |
NBR |
1 |
| 17 |
NUT |
BRASS CW617N UNI EN 12165 |
1 |
| 18 |
NUT |
STEEL A2 UNI 5588 |
1 |
| 19 |
SCREW |
STEEL |
1 |
| 20 |
SCREW |
BRASS CW614N UNI EN 12164 |
1 |
| 21 |
EXPANDER WASHER |
STEEL DC04 UNI EN 10020 |
1 |
| 22 |
WASHER |
BRASS CW614N UNI EN 12164 |
1 |
| 23 |
WASHER |
BRASS CW614N UNI EN 12164 |
1 |
| 24 |
SHUTTER UNIT |
BRASS CW614N UNI EN 12164 |
1 |
| 25 |
CHECK VALVE |
- |
1 |
| 26 |
OBSTRUCTOR |
BRASS CW614N UNI EN 12164 |
1 |
| 27 |
DRAIN |
BRASS CW614N UNI EN 12164 |
1 |
| 28 |
MEMBRANE |
NBR |
1 |
| 29 |
STRAINER/SEAL |
STAINLESS STEEL AISI 316 HOSTAFORM |
1 |
